チェーンコンベヤの仕組み
The chain conveyor (referred to as “スクレーパーチェーンコンベア“) is a new generation of conveying equipment developed by Darko manufacturer. We integrate the advantages of similar domestic products and address common issues encountered in the practical application of general conveying equipment. Its principles are advanced, and its structure is innovative and rational, making it efficient and energy-saving. It is an ideal replacement for スクリューコンベアこのような産業は、建築材料、化学、火力発電、穀物加工、鉱業、機械、冶金、輸送、港湾などに広く応用されている。
There is internal friction and pressure between the particles of bulk materials. When the conveyor chain and its attachments move, the bulk material experiences a pulling force in the same direction as the chain’s movement, which increases the internal pressure between the particles. This, in turn, increases the internal friction among the bulk materials. When this internal friction exceeds the friction between the bulk material and the side walls of the trough, the materials will move forward in the direction of the chain’s motion. The increased internal pressure ensures a stable state among the layers of bulk material, resulting in a continuous flow like that of water. ( When the ratio of the height of the material layer to the height of the trough meets certain conditions, the flow of material is stable, and the flow rate is approximately equal to the chain speed.)
仕様パラメーター
名称 仕様 | X(G)Z- 06 | X(G) Z-08 | X(G) Z-10 | X(G) Z-12 | X(G)Z- 14 |
搬送能力(t/h) | 100-300 | 200-500 | 300-600 | 400-800 | 500-1000 |
チェーン速度(m/s) | 0.48-0.76 | 0.48- 0.76 | 0.48 0.76 | 0.48- 0.76 | 0.48-0.76 |
搬送距離 (m) | 6.7-64.3 | 6.7-64.3 | 6.7-64.3 | 6.7-64.3 | 6.7-64.3 |
材料の粒子径 (mm) | <200 | <300 | <300 | <300 | <300 |
スクレーパー幅 (mm) | 600 | 800 | 1000 | 1200 | 1400 |
スクレーパーの間隔 | 1024 |
ダーコ'ハイライト
特徴 | 説明 |
大きな積載量 | スクレーパーコンベアは、小型で搬送能力が大きいという利点がある。スクレーパーコンベアーのスペースは、従来のコンベアーの1/5で済みます。 ベルトコンベヤ スクリューコンベヤの2/3のスペースで同じ流量の原料を輸送できます。搬送能力は6m3/h~500m3/hです。 |
長寿命・低コスト | スクレーパーコンベアチェーンは 合金鋼 科学的な熱処理加工による通常の寿命は5年以上です。また、チェーン上のローラーの寿命は1年以上です(機械全体の中で最も脆弱な部分)。これにより、年間メンテナンスは1回未満となり、使用コストを大幅に削減し、生産効率を向上させます。 |
低エネルギー消費 | チェーンコンベヤは、材料の内部摩擦を利用して、可動部品によって行われる仕事の大部分を有効な仕事に変換します。チェーンフック輸送を使用すると、それに対する材料の抵抗が大幅に減少し、そのエネルギー消費量はスクリューコンベアの30%〜60%にすぎません。 |
密閉された安全な空間 | 全体のスカーパーマシンは完全に密封され、粉塵シームレスな掘削、防水、防雨、操作が簡単で、安全で信頼性の高い操作を行います。 |
柔軟なプロセス | チェーンマシンは、ケーシングのどの位置でも様々なタイプの注入口と排出口が可能です。高架式、地上式、ピット式があり、水平または上向き(≤15°)に取り付けることができます。 |
どのような素材が使用可能か 運ばれた?
チェーンコンベヤは、1000種類以上の粉体、粒体、小塊状の原料を搬送することができます。代表的なものには次のようなものがあります:
- セメント
- セメント原料
- 黄砂
- 石灰石パウダー
- 石炭粉
- コークパウダー
- フライアッシュ
- 木屑
- クラッシュアイス
- 石粉
- 尿素
- 合成肥料
- 粉石けん
- ソーダパウダー
- 炭酸ナトリウム
- グラファイト
- プラスチックペレット
- ポリエチレン
- 樹脂
- 硫酸カリウム
- 硫化アンモニウム
- クレイパウダー
- 石英砂
- 鉄鉱石粉
- 粉砕スラグ
- 食卓塩
- スターチ
- 小麦
- 綿実
- 粉砕飼料
- マルトース
- 米
- トウモロコシ
- 大豆
By choosing Darko’s Chain Conveyor, you will gain an efficient and durable material handling device that enhances the overall efficiency and reliability of your production line. Whether in the セメント, 採掘この装置は、化学産業や食品産業で信頼性の高いサポートを提供します。
より詳しい情報や技術的なお問い合わせは、当社の営業チームまでお気軽にご連絡ください。
